Solis 8KW Hybrid Solar Inverter (230V, Single Phase) - Smart Energy Management for Bangladesh Homes

Overview

Step into the future of energy independence with the Solis 8KW Hybrid Solar Inverter, a state-of-the-art solution designed to empower homes and small businesses across Bangladesh. This single-phase, 230V inverter seamlessly integrates solar power, battery storage, and grid electricity, offering unparalleled flexibility and reliability. Manufactured by Solis (Ginlong Technologies), a global leader in inverter technology, this 8KW hybrid inverter is engineered to maximize your solar energy harvest, reduce electricity bills, and provide continuous power during grid outages, a critical advantage in the Bangladesh market.

The Solis 8KW Hybrid Solar Inverter is more than just an inverter; it's a comprehensive energy management system. It intelligently manages power flow, prioritizing solar energy for consumption, storing surplus in batteries, and feeding excess back to the grid (where allowed). With its robust design and advanced features, it ensures your energy supply is stable, sustainable, and cost-effective. Experience peace of mind knowing your home or business in Bangladesh is powered by a reliable, efficient, and smart solar solution.

Key Features & Benefits

Seamless Hybrid Functionality

• Intelligent Energy Management: Automatically switches between solar, battery, and grid power sources to optimize energy usage and ensure uninterrupted supply. This feature is particularly beneficial for managing load shedding common in various parts of Bangladesh.
• Grid-Tie & Off-Grid Capability: Functions as both a grid-tied inverter, feeding excess solar power back to the utility, and an off-grid inverter, providing backup power from batteries during blackouts.
• Self-Consumption Optimization: Prioritizes using solar power directly, then charging batteries, and finally exporting to the grid, maximizing your savings on electricity bills in Bangladesh.

High Efficiency & Reliability

• Outstanding Efficiency: Achieves a maximum efficiency of 97.6% (Euro efficiency 97.0%), ensuring more of your generated solar power is converted into usable electricity.
• Dual MPPT Design: Equipped with two Maximum Power Point Trackers (MPPTs), allowing for flexible design with varying orientations or types of solar panels, optimizing energy harvest even in complex rooftop layouts common in Bangladesh.
• Wide PV Voltage Range: Operates efficiently across a broad PV input voltage range, ensuring consistent performance throughout the day and in varying weather conditions.

Advanced Battery Management

• Flexible Battery Compatibility: Compatible with both lead-acid and lithium-ion batteries, offering flexibility in choosing the best storage solution for your needs and budget in Bangladesh.
• High Charge/Discharge Current: Supports a maximum charge/discharge current of 100A, enabling rapid battery charging and efficient power delivery during peak demand or emergencies.
• Intelligent Battery Protection: Features advanced battery protection mechanisms, including overcharge, over-discharge, and over-temperature protection, extending battery lifespan.

Robust Protection & Safety

• Comprehensive Protection: Built-in protections against DC reverse polarity, AC short circuit, output overcurrent, overvoltage, and islanding ensure the safety of your system and appliances.
• IP65 Rating: Designed with an IP65 ingress protection rating, making it suitable for outdoor installation and capable of withstanding harsh environmental conditions prevalent in Bangladesh.
• Anti-Islanding Protection: Automatically disconnects from the grid during power outages to prevent back-feeding, ensuring the safety of utility workers.

Smart Monitoring & Communication

• Integrated Wi-Fi/GPRS: Comes with built-in Wi-Fi or GPRS module for remote monitoring via the SolisCloud platform, allowing you to track your system's performance from anywhere in Bangladesh or abroad using your smartphone or computer.
• Real-time Data Access: Provides real-time and historical data on energy production, consumption, battery status, and grid interaction, empowering you to make informed energy decisions.
• Remote Firmware Updates: Supports remote firmware upgrades, ensuring your inverter always has the latest features and optimizations without requiring a technician visit.

Easy Installation & Maintenance

• Compact & Lightweight Design: With dimensions of 505 x 380 x 170 mm and a weight of just 17.5 kg, it's easy to handle and install in various locations.
• User-Friendly Interface: Features an intuitive LCD display for easy configuration and status monitoring.
• Fanless Design: Operates silently with a fanless design, making it suitable for residential environments.

Technical Specifications

Parameter	Value
PV Input (DC)
Max. PV Input Power	10000W
Max. DC Input Voltage	600V
Rated Voltage	360V
MPPT Voltage Range	90-520V
Min. Input Voltage / Start-up Voltage	90V / 100V
No. of MPPTs / Strings per MPPT	2 / 1
Max. Input Current per MPPT	16A
Max. Short Circuit Current per MPPT	25A
Battery Input/Output (DC)
Battery Type	Lead-acid or Li-ion
Battery Voltage Range	40-60V
Max. Charge/Discharge Current	100A
Max. Charge/Discharge Power	5000W
AC Output (On-Grid)
Rated AC Output Power	8000W
Max. AC Apparent Power	8800VA
Max. AC Output Current	38.1A
Nominal AC Voltage	230V (Single Phase)
Nominal AC Frequency	50Hz / 60Hz
Power Factor	>0.99 (adjustable 0.8 leading to 0.8 lagging)
THDi	<2%
AC Output (EPS Backup)
Max. EPS Output Power	8000W
Max. EPS Output Current	38.1A
Nominal EPS Voltage	230V (Single Phase)
Nominal EPS Frequency	50Hz / 60Hz
Switching Time	<20ms
Efficiency
Max. Efficiency	97.6%
Euro Efficiency	97.0%
Battery Charge/Discharge Efficiency	94.0%
Protection
DC Reverse Polarity Protection	Yes
AC Short Circuit Protection	Yes
Output Over Current Protection	Yes
Output Over Voltage Protection	Yes
Islanding Protection	Yes
Surge Protection	DC Type II / AC Type II
General Data
Dimensions (W x H x D)	505 x 380 x 170 mm
Weight	17.5 kg
Operating Temperature Range	-25°C to +60°C (derating above 45°C)
Humidity	0-100% (non-condensing)
Self-Consumption (Night)	<10W
Topology	Transformerless
Cooling	Natural Convection (Fanless)
Protection Degree	IP65
Noise Emission (Typical)	<25 dB
Display	LCD, LED Indicators
Communication	RS485, Wi-Fi / GPRS (optional external module), DRM, USB
Warranty	5 Years Standard (extendable to 10 years)

Why Choose the Solis 8KW Hybrid Inverter in Bangladesh?

The Solis 8KW Hybrid Solar Inverter is perfectly suited for the dynamic energy landscape of Bangladesh. With its ability to provide uninterrupted power during frequent load shedding, significantly reduce monthly electricity bills, and contribute to a greener environment, it offers a compelling value proposition. Bangladeshi households and businesses can greatly benefit from its intelligent energy management system, ensuring power stability and cost savings.

• Reliable Backup Power: Say goodbye to disruptions caused by load shedding. The Solis 8KW Hybrid Inverter provides seamless transition to battery power, keeping your essential appliances running without interruption.
• Significant Bill Reduction: By maximizing self-consumption of solar energy and reducing reliance on grid power, you'll see a noticeable decrease in your electricity expenses.
• Future-Proof Investment: As energy costs rise and environmental concerns grow, investing in a robust solar hybrid system like the Solis 8KW positions you for long-term energy independence and sustainability.
• Trusted Brand: Solis is a globally recognized brand known for its high-quality, reliable, and innovative inverter solutions. Choosing Solis means choosing a product backed by extensive research and development.
• Local Support: With a growing presence and dealer network for Solis products, finding support and service for your Solis 8KW Hybrid Solar Inverter in Bangladesh is becoming increasingly accessible.

Ideal Applications

This versatile 8KW hybrid inverter is an excellent choice for a variety of applications:

• Residential Homes: Powering medium to large homes, ensuring continuous electricity for all appliances, including ACs, refrigerators, and entertainment systems.
• Small Businesses & Offices: Providing reliable power for critical operations, computers, lighting, and communication systems, minimizing business disruption.
• Remote Locations: Ideal for areas with unreliable grid access, offering a robust and self-sufficient power solution.
• Eco-Conscious Consumers: For those committed to reducing their carbon footprint and embracing renewable energy in Bangladesh.

Installation & Usage Guidelines

For optimal performance and safety, the installation of the Solis 8KW Hybrid Solar Inverter should always be performed by a certified and experienced solar professional. This ensures proper wiring, configuration, and adherence to local electrical codes in Bangladesh. Key steps include:

1. Site Assessment: Determining the best location for the inverter (e.g., cool, dry, well-ventilated area, away from direct sunlight).
2. Mounting: Securely mounting the inverter to a wall using the provided bracket.
3. Wiring: Connecting PV strings, battery bank, grid input, and AC load output according to the detailed instructions in the user manual.
4. Configuration: Setting up operational parameters via the LCD display or SolisCloud platform, including battery type, charge/discharge limits, and grid interaction settings.
5. Monitoring: Utilizing the SolisCloud app or web portal to monitor system performance, diagnose issues, and receive alerts.

Regular maintenance, such as checking connections and keeping the inverter clean, will ensure its longevity and efficient operation.
